Not sure if I mentioned this before or not, but the system seems to lose track of what I've read. I'll have read something several days ago (example, something posted Feb. 3rd) and come back today to see it is now unread and appearing in the new items.

After doing some more reading (and a PM from digger945), I think I will try increasing the gate stoppers from 47 ohms to 100-120 ohms. From the device datasheets, the J device has a typ. input capacitance of 90pf, whereas the K device is 120pf. Since I am only seeing this on the tops of the waveforms, it would appear that the K devices are marginally unstable. I tried putting a 33pf from the gate to drain on the K devices, but mis-connected them to the gate-source pins. They didn't seem too happy with that, and remained unhappy once I removed the caps Not sure if I toasted them or not...

I'm using a portable CDP with a test CD. As you turn the volume up, you can see it on both the input and the output. I believe it is being fed back via the feedback. The input waveform by itself is clean at any volume setting. It did the same thing feeding it with a computer generator via my M-Audio FW. Yes, a real signal generator would be nice, but I don't have one

Did some testing at both x11 and x5.5 gain. Still seeing some oscillation on the tops of the waves at full volume. Used my load box (not sure if it was amb or tangent that had posted that), with loads of none, 33 and 330 ohms. Waveform looks good at all volumes at 330 ohm load. Some oscillation present on 33 ohm load, and no load. gain 11, volume at ~90%. Top is input, bottom is output Gain 11, volume 100%. Putting my hand across the angle bracket and caps (above the board, not touching it) can eliminate most if not all the oscillation. Parasitics? Also, before any of these shots, I removed all sockets (R17-R20), but installed a socket for R55. I also went back to R17-R18 at 3.3K, with a 20K pot. The oscillation seems to be worse the higher the bias. I think I will go for 75-100mA bias on mine. At 75mA and no load, most of the time there is no oscillation present. At 150mA, gain 5.5, there is oscillation present at pot all the way down at all loads other than 330 ohm.

Did some more looking last night, and I am pretty sure the oscillation I was seeing was from the scope probes. It seemed more prevalent on the N-channel source resistors than on the P channel. I was clipping the scope probe to the output side if these and grounding the probe to the PCB ground. If I moved the scope probe perpendicular to the board, the oscillation goes away completely. I was also testing the board with no load on the output, so I should probably use a load of some sort. I saw what looked to be oscillation on the tops of a sine wave, but I think I may have been overdriving it as it went away when the volume was reduced some from max on the pot. More looking today and will settle on bias current. I am thinking about dropping it down from the 150mA to 75mA or so. I don't think a stereo board pair will run off a single sigma22 at more than 150mA without doing some more serious heatsinking. I have run some RMAA tests on the one board (in mono). When in mono mode, RMAA does some sort of phase tests (shown on the opposite channel graphs) which I don't know how to interpret. I'll try to post one and see if anyone can explain it to me or tell me if it is a good or bad result

Talked to Kevin via PM a couple of times tonight. He sent me a pic of his board, so I've been going though it and have a discrepancy. R31-R34 on his board are 100R. In the Eagle files I have (which match his prototype and not the final group buy boards), the Eagle schematic says 10R, which is what I used. However, if I highlight R34 on the board in Eagle, it says 100R (these are the combo 0805/RN55 resistor packages that Jacob used on the board). So, which is right? I think I will go with 100R and see what happens. In the pic, for the Vbe multiplier, he has R17-R18 as 10K, I assume a 20K pot, and 4.75K for R19-R20. IIRC, he said in the thread that he changed the 5K resistors to 2K, so he may have replaced these since the pic was taken. EDIT: Was looking at the wrong resistors. 10R is correct.

Pulled one pair of output devices. Oscillation seems to be gone as far as I can see on the scope. However, running a sine wave thru it, it is obvious that there is still some oscillation present looking at the waveform instability. From a DC perspective, the bias, etc. seemed stable. Looking at waveforms, it is obvious it is not. Interestingly, I had pulled the 220pf input cap. This resulted in oscillation only when the volume pot was all the way down (or almost) or all the way up. Once I replaced the cap, this went away. Summary of changes to this point: 1) R17-R18 2.2K 2) R19-R20 2K 3) R62 1K 4) VR3 2K 5) One set of VAS transistors removed (Q11 and Q12) 6) Removed one pair of output devices (so only one pair installed) 7) Minor deviation from BOM: the bypass caps spec'd as 10nf are implemented as 22nf ERO MKP1837. Some of these changes are bandaids as the thing should run with all 4 sets of output devices, etc. I'm running out of ideas...

Pulled Q11 and Q12... no joy. Initially looked like it had done it, but as soon as I connect anything to the input, it oscillates. I'll poke around some more. I would guess that the board would not like running without feedback? I assume feedback will inject oscillation back into the input? Any other input welcome. I have not looked at the rails yet, etc. Power is from a known good sigma22.

Worked on the second board tonight, and then started doing some measurements etc. on the completed one. I seem to be seeing some oscillation on it. With the input grounded, I am seeing something in the range of 220mVp at around 62.5MHz (scale 0.02us/div, 0.8 divisions... think I calculated the frequency correctly?). This is at the default gain (1K, 100 ohm, so 11?) with a 10pf compensation cap (mica). Also, decreasing bias as far as I could (224mV or 112mA) did not have any effect. I'm currently running at 150mA bias. Varying which feedback method was used made no change. Any thoughts? I do have the gain resistor (R55) as well as R17/R18 and R19/R20 socketed. EDIT: After looking back at some of Jacob's posts, he seems to indicate that the paralleled VAS transistors might be causing some problems? These would be Q9/Q11 and Q10/Q12 on the schematic? I may try pulling one on each side and see what that does...
